Bilstein 24-336970 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber

Name: Bilstein 24-336970 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
Brand: Bilstein
SKU: BLS-24-336970
Price: 234.18 CAD
Availability: InStock
Rating: 4.9 (479 reviews)

SKU: BLS-24-336970

$234.18 CAD

~~$361.69 CAD~~ -35% $234.18 CAD

In stock

Same Day Shipping

Cutoff Time: 1:00 PM EST

Free Shipping!

VIN (optional)

If provided, we'll verify fitment before your order ships and contact you if the selected part is incompatible. Enter your VIN, then add the product to your cart.

Product details

Part Name Shock Absorber
Position Front
Brand Bilstein
Country of Manufacture Mexico
Part Number 24-336970
UPC 651860943244

Estimate Delivery Date

Postal Code (First 3 Characters)

Have Questions?

Ask our experts via Live Chat at the bottom right corner of this page.

Fitment is guaranteed:

If your vehicle is listed on the fitment table below, the product will fit your car - we guarantee it. All you need to do is to ensure that the vehicle's Year, Make, Model, Trim, and any other notes specified inside the fitment table are respected.

Included warranty:

This product has 2-year limited warranty.

Warranty starts from the date of delivery.
Proof of purchase required for all claims.
Covers manufacturing defects only.
Does not cover normal wear & tear.
Does not cover cosmetic damage or rust damage.

To initiate a claim, simply send an email to support@partspioneer.ca. For more information, read our Warranty Policy.

Choose Bilstein because:

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Characteristics include:

Adjustable Damping:Non-Adjustable
Body Design:Snap Ring Grooved Body (Coilover)
Boot Included:No
Collapsed Length (IN):16.91
Collapsed Length (MM):429.6
Extended Length (IN):22.41
Extended Length (MM):569.1
Finish:Zinc Plated
Internal Design:Monotube
Lower Mount Type:Crossbar
PartType:Shocks / Struts
Piston Diameter:46mm
Prop 65 (Y/N):Y
Prop 65 - Short Label:WARNING: Cancer &amp
Reproductive Harm - www.P65Warnings.ca.gov
Reservoir:No
Segment:Light Truck
Series:B8 5100 (Ride Height Adjustable)
Shaft Diameter:18mm
Spring Seat Included:Yes
Stroke/Travel Length (IN):5.50
Stroke/Travel Length (mm):139.7
Title:Bilstein Shock Absorbers
Upper Mount Type:Stem

Customer Video Reviews

Watch genuine customer videos showing their upgrades and honest results of similar products

Fitment Table

This product is compatible with these vehicles:

Year	Make	Model	Notes	Position
2020	Ford	F-150	King Ranch Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2020	Ford	F-150	King Ranch Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2020	Ford	F-150	King Ranch Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2020	Ford	F-150	Lariat Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2020	Ford	F-150	Lariat Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2020	Ford	F-150	Lariat Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2020	Ford	F-150	Lariat Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2020	Ford	F-150	Limited Provides 0-2" Front Lift 4WD	Front
2020	Ford	F-150	Platinum Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2020	Ford	F-150	Platinum Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2020	Ford	F-150	Platinum Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2020	Ford	F-150	XL Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2020	Ford	F-150	XL Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2020	Ford	F-150	XL Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2020	Ford	F-150	XL Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2020	Ford	F-150	XL Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2020	Ford	F-150	XLT Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2020	Ford	F-150	XLT Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2020	Ford	F-150	XLT Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2020	Ford	F-150	XLT Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2020	Ford	F-150	XLT Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2019	Ford	F-150	King Ranch Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2019	Ford	F-150	King Ranch Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2019	Ford	F-150	King Ranch Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2019	Ford	F-150	Lariat Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2019	Ford	F-150	Lariat Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2019	Ford	F-150	Lariat Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2019	Ford	F-150	Lariat Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2019	Ford	F-150	Limited Provides 0-2" Front Lift 4WD	Front
2019	Ford	F-150	Platinum Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2019	Ford	F-150	Platinum Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2019	Ford	F-150	Platinum Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2019	Ford	F-150	XL Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2019	Ford	F-150	XL Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2019	Ford	F-150	XL Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2019	Ford	F-150	XL Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2019	Ford	F-150	XL Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2019	Ford	F-150	XLT Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2019	Ford	F-150	XLT Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2019	Ford	F-150	XLT Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2019	Ford	F-150	XLT Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2019	Ford	F-150	XLT Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2018	Ford	F-150	King Ranch Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2018	Ford	F-150	King Ranch Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2018	Ford	F-150	King Ranch Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2018	Ford	F-150	Lariat Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2018	Ford	F-150	Lariat Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2018	Ford	F-150	Lariat Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2018	Ford	F-150	Lariat Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2018	Ford	F-150	Limited Provides 0-2" Front Lift 4WD	Front
2018	Ford	F-150	Platinum Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2018	Ford	F-150	Platinum Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2018	Ford	F-150	Platinum Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2018	Ford	F-150	XL Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2018	Ford	F-150	XL Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2018	Ford	F-150	XL Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2018	Ford	F-150	XL Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2018	Ford	F-150	XL Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2018	Ford	F-150	XLT Provides 0-2" Front Lift 2.7L 6 Cylinders 4WD	Front
2018	Ford	F-150	XLT Provides 0-2" Front Lift 3.3L 6 Cylinders 4WD	Front
2018	Ford	F-150	XLT Provides 0-2" Front Lift 3.5L 6 Cylinders 4WD	Front
2018	Ford	F-150	XLT Provides 0-2" Front Lift 5.0L 8 Cylinders 4WD	Front
2018	Ford	F-150	XLT Provides 0.5-2.5" Front Lift 3.0L 6 Cylinders 4WD	Front
2017	Ford	F-150	King Ranch Provides 0-2" Front Lift 4WD	Front
2017	Ford	F-150	Lariat Provides 0-2" Front Lift 4WD	Front
2017	Ford	F-150	Limited Provides 0-2" Front Lift 4WD	Front
2017	Ford	F-150	Platinum Provides 0-2" Front Lift 4WD	Front
2017	Ford	F-150	XL Provides 0-2" Front Lift 4WD	Front
2017	Ford	F-150	XLT Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	King Ranch Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	Lariat Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	Limited Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	Platinum Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	XL Provides 0-2" Front Lift 4WD	Front
2016	Ford	F-150	XLT Provides 0-2" Front Lift 4WD	Front
2015	Ford	F-150	King Ranch Provides 0-2" Front Lift 4WD	Front
2015	Ford	F-150	Lariat Provides 0-2" Front Lift 4WD	Front
2015	Ford	F-150	Platinum Provides 0-2" Front Lift 4WD	Front
2015	Ford	F-150	XL Provides 0-2" Front Lift 4WD	Front
2015	Ford	F-150	XLT Provides 0-2" Front Lift 4WD	Front
